U10 XGS-PON OLT

Key Features

Carrier-grade PON, without the chassis

U10 packs high-density XGS-PON into a 1U standalone unit — easy to install, easy to commission, and ready for multi-vendor networks.

Dual-mode PON, hot-switched

Each of the 8 PON ports runs XG(S)-PON by default (XGS-PON 10G/10G, XG-PON 10G/2.5G) and can be hot-switched to GPON mode individually — upgrade or reuse existing fiber without hardware swaps.

Full line-speed forwarding

1×GE (RJ45) + 4×25GE (SFP28) + 2×100GE (QSFP28) uplinks on a 1,960 Gbps backplane with 566.9 Mpps forwarding — no bottleneck at the aggregation layer.

Complete L2/L3 feature set

32K MAC, 4K VLANs, QinQ, LACP, QoS, IGMP snooping, DHCP server/relay, static + OSPF/RIP routing, T-CONT DBA and x-GEM — the full carrier feature stack in a pizza box.

Hardened for the field

6 kV power and 4 kV interface lightning protection, −20°C to +60°C operating range, 4-fan cooling, and AC 100–240 V power — built for central offices and remote sites.

Front Panel

Every port, labeled

The full front-panel layout — PON, uplinks, management and indicators at a glance.

1

2

3

4

5

1

Status LEDs & resetSYS / PWR1 / PWR2 indicators, RST button, USB port

2

PON 1–8 (SFP+ slots)XG(S)-PON default · Class N1/N2 — each port hot-switchable to GPON (Class B+ → C++++)

3

4× 25GE uplink (SFP28)1/10/25GE ports 1–4 for aggregation

4

2× 100GE uplink (QSFP28)Ports 5–6, 25GE / 50GE / 100GE

5

ManagementGE7 out-band port, Console, USB-C console, USB 3.0, MicroSD, AUX

Applications

Deployed your way

Three reference topologies — each built from UGrid products that work together end to end.

Carrier FTTH / greenfield

U10 feeds 1:256-split PON trees to UGrid XGS-PON or GPON ONTs. Dual-mode ports let you mix both on the same chassis during migration.

Enterprise / campus PoL

U10 aggregates FiberTrix GPON PoE switches — fiber to the floor, PoE to APs and cameras, all managed from one OLT.

Monitored FTTx

Pair with the uFT intelligent fiber testing system — real-time OTDR fault detection plus AI degradation forecasting on the same outside plant.

Specifications

Technical specifications

Every value below is from the official U10 spec sheet. Contact us for the full datasheet and interoperability test reports.

PON
PON ports	8 × SFP+ slots, XG(S)-PON mode by default
XGS-PON rate	10 Gbps upstream / 10 Gbps downstream
XG-PON rate	2.5 Gbps upstream / 10 Gbps downstream
GPON mode	1.244 Gbps upstream / 2.488 Gbps downstream — each port hot-switchable to GPON
Optical class	XG(S)-PON: Class N1/N2 · GPON: Class B+ / C / C+ / C++ / C+++ / C++++
Wavelength	XG(S)-PON: 1270 nm up / 1577 nm down · GPON: 1310 nm up / 1490 nm down
Max split ratio	1:256 (maximum) · 1:128 (recommended)
Max ONUs	2,048 per unit
Transmission distance	20 km
Uplinks & switching
Uplink ports	1 × GE (RJ45) + 4 × 25GE (SFP28) + 2 × QSFP28 (25GE / 50GE / 100GE)
Backplane bandwidth	1,960 Gbps
Forwarding rate	566.9 Mpps
Layer 2 / Layer 3
Layer 2	32K MAC · 4,096 VLANs · port VLAN, tag/untag, transparent, translation, QinQ · storm control · port isolation & rate limiting · 802.1D/802.1W · static/dynamic LACP · QoS (port/VID/TOS/MAC) · ACL · IEEE 802.x flow control
Multicast	IGMP snooping · 2,048 IP multicast groups · MLD v1/v2 snooping · IGMP proxy
DHCP	DHCP server · DHCP relay · DHCP snooping · option 82
Layer 3	ARP proxy · 4,096 hardware host routes / 512 subnet routes · 802.1X, RADIUS, TACACS+ · IP source guard · static route, RIP v1/v2, RIPng, OSPF v2/v3, NDP · IPv6
PON functions	T-CONT DBA · x-GEM traffic · data encryption · ONT auto-discovery / link detection / remote upgrade · power-off alarm · broadcast-storm resistance · RSTP
Management
Management interfaces	CLI (Console / Telnet / SSH) · WEB · SNMP (EMS) · out-band 10/100/1000BASE-T · Console port · USB 3.0 · Type-C USB console · MicroSD
Management functions	Fan-group control · port status monitoring & configuration · online ONT configuration & management · user management · alarm management
Power & environment
Power supply	AC 100–240 V (rated 110/220 V)
Power consumption	150 W
Cooling	4 fans
Lightning protection	6 kV (power) · 4 kV (interfaces)
Operating environment	−20°C to +60°C · 5%–95% humidity (non-condensing)
Storage environment	−40°C to +85°C · 5%–95% humidity (non-condensing)
Dimensions	442 × 330 × 43.6 mm (L × W × H), 1U
Weight	4.2 kg (single power)

Interoperability

Tested to interwork

U10 is standards-based (ITU-T G.9807 / G.987) and interworks with ONUs from multiple vendors.

UGrid ONTs — verified

UNT XGS-PON ONT ✓ Verified
UNT GPON SFP ONT ✓ Verified

Third-party ONUs

Multi-vendor G.9807 / G.987 ONUs ✓ Interwork

Bringing your own ONUs? Send us the models — we run interoperability testing on request and share the test report. Full third-party compatibility list is published with each test report.

Downloads

Documentation & software

Everything engineers and procurement need — one click away.

U10 Spec Sheet (PDF)U10 XG(S)PON OLT · official specifications

Download

User Manual (PDF)Installation, commissioning and management guide

Coming soon

FirmwareLatest stable release + release notes

Coming soon

MIB FilesSNMP MIB for EMS integration

Coming soon

Interoperability Test ReportThird-party ONU test results

Coming soon

Ordering

Ordering information

U10 XG(S)-PON OLT

Base unit — 1U standalone OLT, 8× SFP+ PON slots, AC 100–240 V (single power)
PON optics — XGS-PON Class N1/N2 modules for XGS mode; Class B+ through C++++ modules for GPON mode (per-port hot switch)
Uplink optics — QSFP28 ports support 25GE / 50GE / 100GE transceivers

Compare

U10 or U5?

Choosing between XGS-PON and GPON comes down to bandwidth and reuse.

	U10 XGS-PON OLT	U5 GPON OLT
PON standard	XGS-PON / XG-PON + per-port GPON	GPON
PON ports	8 (SFP+)	1 / 4 / 8 / 16
Per-port rate	10G symmetric (XGS) · 10G/2.5G (XG)	2.5G down / 1.25G up
Max split ratio	1:256 (1:128 recommended)	1:128
Max ONUs	2,048	2,048
Uplinks	1×GE + 4×25GE + 2×100GE	10GE + GE
Best for	Greenfield 10G FTTH, high-bandwidth enterprise, future-proof builds	Cost-effective GPON FTTH, brownfield with existing GPON ONUs
